TMP-700

Short Description:

Raysince fully automatic tunnel car wash machine uses high-pressure water and seven brushes to provide efficient and fast washing. It supports 24-hour unattended operation and features high water recycling efficiency, simple maintenance, and low operating costs. After washing, the vehicle’s paint surface becomes hydrophobic, shiny, and retains its gloss for a long time. Suitable for passenger cars, SUVs, MPVs, and commercial vehicles with up to 10 seats.

Send email to us

Product Detail

Product Tags

Technical Specification

Technical Specification
Overall Size (mm)	710036603000
Flat Conveyor Length	8850 mm
Frame Material	Stainless Steel
Washing Capacity	40 Vehicles/H
Machine Total Weight	4500 KGS
Washing Process
Water Spray System	1 Set
Shampoo Spraying	1 Set
Wax Spraying	1 Set
Long Vertical Brush	4 Sets
Short Vertical Brush	2 Sets
Horizontal Brush	1 Set
Round Wheel Brush	－
Top Blowers	4 Sets
Side Blowers	Optional
Installation Rerequirement
Water Consumption	120 L per vehicle
Electricity Consumption	0.75kw per vehicle
Site Installation Size (mm)	1000040003200
Power Supply Requirement	3Phase/380V 28-36 KW
Air Supply Requirement	0.25m³/min, 0.8 Mpa (2.2KW)
